🔬 The Science Behind It

It emits at 10,600nm, a far-infrared wavelength with high absorption in water. This lets the laser incise, evaporate, and coagulate tissue with precision while avoiding significant absorption by melanin or oxyhemoglobin — meaning treatment accuracy stays high with minimal scattering or reflection loss, even on pigmented or vascular skin.

• High Accuracy: Low reflection and scattering allow the beam to strike its target with tight precision.
• Safety: Water-selective absorption limits collateral thermal spread to surrounding tissue.
• Effective: Controlled micro-injury triggers the skin's natural collagen remodeling response — visible in the before/during/after tissue cross-section.

✨ Clinical Functions

Improve skin quality and stimulate rejuvenation across six core applications:

🦾 Imported Articulated Arm (South Korea)

• Special Seven-Joint Design: A dedicated seven-joint articulated arm gives the operator full range of motion around the treatment area.
• High-Frequency RF Tube: Long service life paired with higher output quality and consistency.
• 9 Optical Lenses, 99%+ Reflectivity: Smaller energy loss along the beam path translates to higher clinical efficiency.
• Center Red Light Deviation <0.5mm: Delivers highly accurate targeting, especially valuable for small-area lesions.
• Adjustable Aiming Beam (1–5mW): Continuously tunable for clearer visualization during clinical work, while protecting the operator and making the lesion area easy to observe.

⚙️ True Ultra-Pulsed Power Delivery

The terminal laser power is continuously adjustable across a low-power range of 1–40W, meeting precise treatment needs while helping avoid clinical complications.

• True 40W Output to Tissue: Low transmission loss preserves clinical effect at full power.
• Stable Low-End Output: True energy delivery starting from 1W solves the common problem of energy instability at low settings.
• Clean Vaporization Points: During treatment, the true ultra-pulsed CO2 beam produces only controlled white vaporization points — deep penetration with thermal stimulation and thermal damage that stay controllable and limited, unlike less-refined competitor beams.

🏥 Clinical Application & Interface

• Patented Surface Grinding Technology: More effective for treating acne pits and scars.
• Superficial/Deep Alternating Treatment: A unique dual-depth technology mode for versatile tissue response.
• 6 Treatment Modes, 8 Handpieces: Covers the clinical needs of multiple departments from one console.
• Medical Certification-Level Interface: Non-adjustable parameter presets for defined clinical treatments reduce accidents, shorten recovery periods, and improve precision and outcomes.

Touchscreen application presets include: Surface, Deep, Full Layer, Expert, Pigment, Onychomycosis, Skinning, and Privacy modes, each paired with a matched handpiece (F50S, F50SH, F100S, F100SH, F50V, F200, F20DR, F50S, F100V, F50, F100, PHY).

🧩 Accessories

• Facial Treatment Tips: F50S, F50SH, F100S, F100SH — sized for pigment, acne, texture, and onychomycosis (nail fungus) applications.
• Surgical Handpieces: Dedicated handheld units for surgical CO2 laser procedures.

🔲 Spot Pattern Technology

8 spot modes — square, circle, hexagon, rectangle, ellipse, triangle, line, and hollow circle — cover the treatment needs of all body and facial areas.

• Spiral Micro-Beam Scanning: Expands treatment area coverage for efficient skin resurfacing.
• Spiral Thermal Protection Zone: The hollow spiral gap pattern promotes faster skin repair compared to standard fixed-dot grids used by other systems.

🩺 SUI / VR Handles

The newest-generation RF tube supports an exchangeable handpiece for both CO2 fractional laser and ultra-pulsed CO2 laser procedures. This makes it an advanced option for gynecological treatment — stimulating collagen within the vaginal mucous membrane to improve elasticity, address symptoms of stress urinary incontinence, and relieve conditions such as vaginal dryness or vaginitis, using the dedicated:

• SUI Handpiece (Stress Urinary Incontinence)
• VR Handpiece (Vaginal Rejuvenation)

Disposable Sterile Tube

A single-use disposable private sleeve prevents cross-infection between patients — safe, convenient, and suited to both beauty salons and clinical settings.

• Vaginal tightening and elasticity increase
• Collagen remodeling of vaginal tissue
• Treatment of insufficient vaginal secretion
• Vaginal anti-inflammatory support, developing immunity
• Remission of vaginal dryness and urinary incontinence

Vaginal and urinary-health applications should be performed by a trained clinician in accordance with local medical device regulations.

📋 Technical Specifications

Laser Type	UltraPulse and CW
Wavelength	10,600 nm
Power to Tissue	40 W
Display	10.4-inch touch screen
Power of Aiming Beam	≤5 mW
Laser Operating Mode	Ultra pulse, fractional
Scanning Mode	Free scan, sequence scan, interline scan
Scan Area	1×1 – 20×20 mm
Beam Mode	TEM00 < 1.1 M²
Beam Divergence Angle	0.3 mrad
Spot Size	0.12 / 2.0 mm
Spot Pattern	Circle / Ellipse / Triangle / Square / Rectangle / Hexagon / Line / Hollow Circle
Beam Delivery	7-joint articulated arm
Aiming Beam	5 mW, 635nm infrared, adjustable intensity
Cooling System	Air
Electrical	100–240VAC, 50/60Hz
Accessories	Vaginal probes (360° full-angle), VR HP, SUI HP, CO₂ HP (f=50mm / f=100mm)
Dimension	57 × 90 × 136 cm
Weight	80 kg

💼 Why it Fits our Treatment Menu

By combining an internationally certified (ISO13485, CE, FDA, TÜV) resurfacing platform with an interchangeable gynecological applicator, it lets a practice serve dermatology and women's-health treatment demand from one console — reducing floor space, capital outlay, and consumable SKUs versus running separate single-purpose systems.
