Diode Laser Machine
🔬 Theory: How the 808nm Wavelength Works
The 808nm wavelength effectively penetrates deep into the skin and is efficiently absorbed by the target chromophore. With an adequate pulse duration, energy density, and epidermal cooling, the beam creates sufficient thermal damage to the target follicle without damaging surrounding tissue — achieving effective, lasting hair removal. The 808nm diode laser can also work in On-Motion (gliding) mode, making treatments extremely fast and permanent.
🧍 For Operating Parts
The machine can remove hair from different parts of the body, including:
Leg
Armpit
Bikini
Arm
Face
🧩 Accessories
- Imported Connector Spare Parts: Reliable, easily serviceable cable and connector components.
- Strong Radiator: High-capacity cooling core supports sustained treatment sessions.
- UK Flojet Pump: Industry-recognized water circulation pump for consistent cooling performance.
- American Lasertel Laser Bar: A US-sourced laser bar underpins the machine's power and reliability.
✅ Features
No Downtime
Ice Plus Cooling
Safe & Comfortable
Quicker Treatments
Smart Sensing System
Fitzpatrick I–VI & Tanned Skin
🖐️ Handle
- Spot Size 12×18mm with super cooling for consistent, comfortable passes.
- 30,000,000+ Guaranteed Shots: Built for high-volume clinical use over a long service life.
- Double Cooling Pads: Layered cooling contact delivers the best comfort result.
- Laser Bar Imported from USA (Lasertel): A recognized, high-quality laser source.
- Facial Tip Included: Reaches tricky areas such as the ears, nostrils, and glabella.
🌈 Characteristics: 3 Waves, All Skin Tones
| Wavelength | Best For |
|---|---|
| 755nm | White skin — fine, golden hair removal |
| 808nm | Yellow/neutral skin — brown hair removal |
| 1064nm | Black/darker skin — black hair removal |
The combined 755nm / 808nm / 1064nm output is suitable for all kinds of skin, letting one machine safely serve a full range of clients.
📋 Specifications
| Model | LFS-808 |
|---|---|
| Laser Type | Diode Laser |
| Wavelength | 808nm + 755nm + 1064nm |
| Display | 10.4-inch TFT touch screen |
| Laser Power | 1000W |
| Rated Input Power | 1500W |
| Pulse Duration | 1–400 ms |
| Energy | 1–120 J/cm² |
| Spot Size | 12 × 18 mm |
| Repetition Frequency | 1–10 Hz |
| Probe Temperature | -5°C to 5°C |
| Cooling | Water cooling, air cooling, semi-conductor cooling |
🖥️ Platform Specifications
| Electrical | AC 220V 50Hz / AC 110V 60Hz |
|---|---|
| Packing | Aluminum alloy case |
| Dimension | 56 × 56 × 52 cm |
| Weight | 40 kg |
| Color | White |
💼 Why the LFS-808 Fits Your Treatment Menu
With US FDA approval, a triple-wavelength engine covering Fitzpatrick I–VI and tanned skin, and a rugged 30-million-shot handle, the LFS-808 gives clinics a portable machine that doesn't compromise on power or safety — well suited to practices that need clinic-grade results without a bulky, fixed console.
